Positioned under Unilumin’s motto “Make Every Screen a Profit Engine,” the Unilumin UGM II series is a heavy-duty stage rental LED display engineered for concerts, outdoor festivals, conferences, and exhibitions—combining IP65 ingress protection with up to 7,680 Hz high refresh performance.
1.2T Load+40% Cabinet Rib Strength
IP65All-Weather Protection
7,680 HzMax Camera Refresh Rate
800–4,000 nitsBrightness Range (14–16 bit)
1. Structural & Mechanical Highlights
- Upgraded Cabinet Strength (+40%): Multiple internal cabinet ribs increase structural rigidity by 40%, supporting vertical stacking loads up to 1.2 metric tons per cabinet.
- Ergonomic Damping Handle & Visualized Alignment: Thickened smooth handle stays upright for faster transfer, while see-through locating holes speed up vertical and horizontal cabinet alignment.
- Universal Dual-Module Interface (Saves 50% Spares): Modules are interchangeable across left and right positions, cutting the required spare-module inventory by 50% on tour.
2. Fast Tour Maintenance & Auto Calibration
| Maintenance Feature | Engineering Implementation |
|---|---|
| External Rear Locker Fixation | All locker screws are accessible on the rear of the cabinet—no need to remove LED modules to service locks. |
| Retractable Location Pins | Newly designed retractable positioning pins allow single-cabinet removal from the middle of a rigged wall. |
| Independent Patent Signal Port | Signal connector can be serviced independently without disassembling the main power box. |
| Automatic Calibration Upload | When a module is swapped, stored calibration data uploads automatically to maintain uniform brightness and chromaticity. |
In-Stock Refurbished Unilumin UGM II Batches at Stellux
Stellux currently stocks two matched 2023-vintage Unilumin UGM II P3.91 outdoor rental lots, fully tested under load:
